Description

Description
Manufacturing the 8 production lines including jamming modules, complete units, detection equipment, and fusion products
1. Handheld Detection Systems
C9 Pro Handheld Drone Detector
The flagship handheld detector with FPV video capture and Remote ID capabilities .

Parameter Specification
Model C9 Pro
Frequency Range 100MHz – 6GHz
Detection Radius 1-2km (urban), 2-3km (open environment)
Targeting Range 1-2km (urban), 2-3km (open)
Response Time 3-5 seconds
Simultaneous Detection ≥10 drones
Weight 658g ±10g (with antenna)
Dimensions 185mm × 80mm × 33mm
Battery Capacity 8000mAh (built-in)
Operating Time ~4 hours (20% screen brightness)
Charging Time ~2.5 hours
Operating Temp -35°C to +50°C
Storage Temp -40°C to +40°C
Screen 6-inch, 2160×1080 pixels
Memory 8GB RAM / 256GB storage
OS Android 12
Key Functions Drone positioning, pilot positioning, 700+ drone library, FPV detection, RID identification (DJI OcuSync, ASTM F3411, GB 42590-2023), blacklist/whitelist, trajectory playback
CH09 (Base Model)
Similar to CH09 Pro but supports vehicle-mounted deployment with roof antenna .

Parameter Specification
Detection Range 3-10km
Weight (Complete) 2.7kg
Unit Weight 0.6kg
Operating Time 4 hours
Frequency Bands 433MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz (more customizable)
CH11 Portable Drone Detector
Suitcase-style portable monitoring platform .

Parameter Specification
Model CH11
Detection Range Up to 5km (detection), 3km (location)
Screen 10.1 inches
Form Factor Portable suitcase design
Capabilities Detection, identification, location, and tracking of drones and pilots
CH11PRO
Box-type detector with extended range .

Parameter Specification
Detection Range Up to 3km (positioning), 5km (spectrum detection)
Frequency 300M-1.5G
CH10 Single-Soldier System
Handheld high-precision integrated detection and positioning system .

Parameter Specification
Features Drone detection, trajectory tracking, pilot positioning, FPV live feed monitoring
CH05 with Wrist Watch Alert
Portable detector with companion wrist watch for alerts .

Parameter Specification
Frequency 70MHz-6.2GHz
Features Team coordination via wrist watch alerts
CH06 Long Range Detector
Parameter Specification
Frequency Range 20MHz-8GHz
Detection Range 3-5km
Features Customizable frequency settings, multi-drone monitoring
2. Fixed/Stationary Systems
TQ01-C Fixed Detection & Jamming System
Integrated fixed installation for permanent site defense .

Parameter Specification
Model T1-C (also T2200-C)
Detection Frequency 70MHz-6GHz full band scanning
Key Detection Bands 800MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz
Detection Distance ≥10km (environment dependent)
Detection Range Horizontal: 360°, Vertical: -90° to +90°
Direction Finding Accuracy ≤±3° RMS
Time to First Detection ≤10 seconds from power-on
Jamming Distance ≥3km (environment dependent)
Jamming Coverage 360° horizontal
Features Full band detection, FPV interference, simulated image transmission jamming, multiple interference modes (directional/omnidirectional), unattended operation, military-grade aluminum housing, signal collection capability
TQ05 UAV Detection and Defense System
High-power fixed system .

Parameter Specification
Frequency Range 70-6000MHz
Output Power 500-1200W (total)
Channel Configuration 8+ channels with individual power specs (example channels shown below)
Sample Channel Configuration :

Channel Frequency Output Power
1 220-350MHz 47dBm (50W)
2 350-470MHz 47dBm (50W)
3 470-600MHz 47dBm (50W)
4 600-730MHz 47dBm (50W)
5 730-910MHz 47dBm (50W)
6 910-1100MHz 47dBm (50W)
7+ Additional bands 47dBm (50W)
Fixed Jamming Box
Outdoor pole/wall-mounted jamming system .

Parameter Specification
Channels 14 channels
Power 100W
Features Weather-resistant (thunderstorms, fog, snow), customizable frequency bands
3. Vehicle-Mounted Systems
T100 / DD100-AB Vehicle-Mounted Integrated System
Comprehensive mobile detection and jamming solution .

Parameter Specification
Model Numbers T100, TD100-AB, D100-AB
Detection Mode Passive (no active emission)
Detection Frequency 300MHz-6GHz (TQDR100); 500MHz-6GHz (TQDR100-AB)
Detection Angle Horizontal 0-360°, Vertical -90° to +90°
Detection Altitude 0-1200m
Detection Radius 5km (environment/drone dependent)
Detection Time ≤5 seconds
Detection Power ≤100W
Jamming Distance ≥3km (environment dependent)
Jamming Range Horizontal 360°, Vertical -90° to +90°
Jamming Frequency Bands 900M/1.2GHz/1.5GHz/2.4GHz/5.2GHz/5.8GHz
Jamming Response Time ≤3 seconds
Total Power Consumption ≤2300W
Mobile Power Runtime ≥30 minutes (full transmission)
Operating Speed Up to 150 km/h
Suppression Distance Ratio ≥15:1 (system-to-drone : drone-to-controller)
Operating Temperature -20°C to +60°C (±2°C)
Storage Temperature -60°C to +85°C (±2°C)
Equipment Weight 64.25kg
Jamming Channels 6 channels with independent control
Jamming Channel Specifications (TQDR100) :

Channel Frequency Range Output Power
CH1 (840±15)MHz – (930±15)MHz 47±3 dBm (~50W)
CH2 (1535±15)MHz – (1635±15)MHz 44±3 dBm (~25W)
CH3 (2380±15)MHz – (2520±15)MHz 47±3 dBm (~50W)
CH4 (5130±15)MHz – (5370±15)MHz 44±3 dBm (~25W)
CH5 (5725±15)MHz – (5885±15)MHz 47±3 dBm (~50W)
CH6 (1080±15)MHz – (1200±15)MHz 44±3 dBm (~25W)
Features :

360° full-frequency detection and jamming

Quick-detach components for mobile/fixed/portable modes

Low wind resistance design for high-speed stability

Blacklist/Whitelist with one-click marking

Expandable for multi-device networking

Military-grade environmental adaptability

Electronic map with real-time positioning

Multi-angle independent on/off control

WS26 Roof-Mounted UAV Jamming Device
Hood-type vehicle-mounted system .

Parameter Specification
Design Hood-type fiberglass enclosure
Channels 8-14 frequency bands (customizable)
Voltage 28V DC
Power 1100W
4. RF Jamming Modules & Components
Hyucx offers modular components for system integrators with aluminum housings and SMA/N-type connectors .

General Module Capabilities
Parameter Specification
Power Range 10W-200W
Frequency Range 100MHz-7500MHz
Technologies GaN, LDMOS, DDS ultra-wideband modules
HY100-5200 GaN Module (5.2/5.8GHz)
High-power module for anti-drone and FPV interference .

Parameter Specification
Model H100-5200
Frequency Range 5150-5350MHz / 5725-5850MHz
Output Power 50.5dBm (100W)
Gain 50dB
Voltage 24-32V DC
Current (Not specified, 100W output)
Dimensions 154.5 × 73 × 26.5mm
Weight 0.85kg
Connector Type N-Type / SMA
Mounting Flange mount
5. Jamming Complete Units (Various Form Factors)
C.T manufactures a wide range of complete jamming systems :

Product Type Description
Handheld Jamming Devices Gun-style portable jammers
Backpack Jammers Man-portable wearable systems
Vehicle-Mounted Jammers Integrated vehicle systems (see TQDR100)
Suitcase Jammers Portable disguised as luggage
Drone Jamming Guns Rifle-style directional jammers
Drone Jamming Shields Protective screening devices
Integrated Detection & Jamming Combined systems (see TQ01-C)
Example: 14-Channel 100W Fixed Jamming Box
Parameter Specification
Channels 14
Power 100W
Frequency Customizable per customer
Application Outdoor pole/wall mounting
Features Weatherproof, automatic strike capability
6. Detection-Only Systems
TQ01 Drone Detector (TDOA Networking)
Passive detection system for multi-unit networked positioning .

Parameter Specification
Type Passive detection only
Technology TA (Time Difference of Arrival) for multi-unit localization
Capabilities Intrusion alarm, identification, direction-finding, networking location
Single Unit Detects and finds drone direction
Multiple Units Networked for precise drone location
WS03 Detection System
Parameter Specification
Frequency 70MHz-6GHz
Features Spectrum detection, automatic countermeasure activation, customizable bands/power
7. Customization Services
C.T offers extensive OEM/ODM services :

Customization Type Options
Nameplate Custom branding
Boot Screen Custom startup display
Product Casing Custom enclosures/colors
Packaging Custom boxes
PCBA Motherboard Custom circuit boards
Integrated Solutions Combined detection, countermeasure, and decoy devices per application
Key Technologies & Capabilities
Technology Description
GaN Modules Gallium Nitride technology for high efficiency, compact size, extended range
LDMOS Laterally Diffused Metal Oxide Semiconductor for robust power amplification
DDS Direct Digital Synthesis for ultra-wideband precision
RID (Remote ID) Protocol decoding for DJI OcuSync, ASTM F3411, GB 42590-2023 compliance
FPV Detection Low-frequency racing drone detection with video demodulation
TDOA Positioning Time Difference of Arrival for multi-unit drone localization
Simulated Image Jamming Interference with analog video transmission
Company & Support Information
Parameter Details
R&D Focus Radio detection, drone positioning, jamming modules, software development for detection systems
Production Lines 8 dedicated lines for modules, jammers, detectors, and fusion products.
________________________________________________________________________________________________________________________________________________

OUR CATALOGUE
Drones are profoundly changing the way people live and work. Drone
defense has also become an important part of maintaining national
and military security. In recent years, the security issues brought by
drones have become increasingly prominent, and the management of
low-altitude drones faces severe challenges.
Anti-drone systems, with their high efficiency, light weight, and
portability, have gradually become important technical equipment for
ensuring public safety and low-altitude protection. W e a r e
committed to providing the world’s leading lowaltitude security solutions to build a shield and protect safety at low
altitudes.
Catalogue
Drone jamming series
• Handheld jamming gun
• Jamming backpack
• Jamming metal backpack
• Fixed jamming box
• Vehicle-mounted jamming box Drone
Detection series
Drone detection& jamming systemDrone defense module
Drone defense accessories
• Fixed drone positioning equipment • Vehicle-mounted drone detection jamming equipment • Suitcase-type drone positioning equipment • Handheld drone positioning equipment • Handheld drone detection equipment • Fixed detection and defense equipment • Vehicle-mounted drone detection and defense system• Detection counter-gun
• Drone detection PCBA board
• RH jamming modules
• Antenna
Ø Handheld Jamming Gun
Ø Jamming Backpack
Ø Jamming Metal Backpack
Ø Fixed Jamming Box
Ø Vehicle Jamming Box
Drone Jamming Series
Name Gun-type countermeasures equipment parameters customization Yes
Interference
frequency
420-450MHZ
825-960MHz 1100-1300MHZ
1360-1450MHZ
1560-1620MHz 2400-2500MHz 5150-5300MHz 5725-5875MHz Function Video intercept, forcedlanding, return,
interception Countermeasure
radius
1000-2500m Directional Antenna Vertical 45° Horizontal 45° Power supply
voltage Charger 220V to DC29.4V
Power supply method Built-in battery24V（5AH）Power of the whole machine
180w Working
temperature
-20℃/ +45℃Size 711*292*71mm Weight of the whole machine
4.5kg Box size 810*430*160mm Machine weight 11kg
LS05
Handheld Jamming gun, built-in 8 sets of RH drone jamming modules, equipped with high-gain directional antenna. It will
intefere the drone’s navigation signal, which forced drone to
land or return to its starting point. Features: 1. Customizable jamming frequency bands;
2. Replaceable battery design, the battery life is 50 minutes;
3. Built-in high-gain antenna jamming range, jamming range 1000 to 2500 meters;
4. Built-in cooling fan design, the device runs continuously;
5. Split modular design, the antenna and the main body can be easily assembled/disassembled, which is convenient for customsclearance;
6. 2x telescope, shockproof design, easy to find and lock the drone.
01 LS05
401
WS08
Fixed Jamming box, built-in 6-8 sets of RH Drone jamming modules, equipped with high gain fixed antennas. It will intefere the drone’s
navigation signal, which forced drone to land or return to its starting point. The jamming angle is 360 degrees or directional 45 degrees. Jamming
range (1000-2000m),and can continuously counter the target drones. Features:
1. Interference frequency band can be customized. 2. Built-in high-gain antenna jamming range, jamming range 1000 to 2000m. 3. The device can be configured with directional or omnidirectional antenna. 4. The antenna and the main body can be easily assembled/disassembled, which is convenient for customs.
01 WS08 WS08S
Interference Frequency
420-450MHZ
825-960MHz 1100-1300MHZ
1360-1450MHZ
1560-1620MHz 2400-2500MHz 5150-5300MHz 5725-5875MHz Function Cut off Image
transmission
eviction, forced
landing
Product size
45*35*15mm (left and
right) Product weight 20kg
Omni- directional counterbalance
1000-2000m
Operating
temperature
-30~70℃
Power supply mode Built-in battery 24V
(30AH)/220V Overall power 300W-400W
Blocking medium
Electromagnetic wave Use place Troops, defence, military industry, armed
police, transport, air defence of large
venues, etc.
WS08S
Jamming metal backpack, built-in 8-12 sets of RH drone jamming modules,Configure a high-gaindirectional
antenna. It will intefere the drone’s navigation signal, which forced drone to land or return to its startingpoint.The jamming angle is 360 degrees or 45 degrees in a directional manner.Jamming range (1000- 3000meters), and has continuous countermeasures against drones. Features:
1. Interference frequency band can be customized. 2. Built-in high-gain antenna jamming range, jamming range 1000 to 2000meters.3. The device can be configured with directional or omnidirectional antennajamming drone. 4. The antenna and the main body can be easily assembled/disassembled, whichisconvenient for customs clearance. 5. The device is configured with a quick switch to freely select the jamming frequency band for
development. 6. Aluminum heat sink with high-efficiency fan to ensure long-term stable operation of the equipment.
Interference Frequency
600-650MHZ
650-700MHz 700-750MHz 750-800MHz 850-950MHz 950-1050MHz 1100-1300MHZ
1360-1450MHZ
1560-1620MHz 2400-2500MHz 5150-5300MHz 5725-5875MHz
Function Cut off Image
transmission
eviction, forced
landing Product size 46.5*38*16.2cm Product weight 31kg Package size 77.5*51*50cm Packing weight 47Kg Directional countermeasure
500-2000m
Omni-directional counterbalance
1000-2000m
Battery capacity Built-in battery 29.4V
(25AH) Working time
45 minutes
(continuous firing
time) Overall power 600W Processing custom Yes
01 WS12 01 WS16
Name Chassis type
countermeasure
equipment
Function
Forced landing, removal
Interference
frequency
320-350MHz 420-450MHZ
825-960MHz 1100-1300MHZ
1360-1450MHZ
1560-1620MHz 2400-2500MHz 5150-5300MHz 5725-5875MHz more Machine weight 52kg
Omni-directional countermeasures
1000-3000m Protection class IP55
Direction of
defence Omnidirectional 360° Whole machine power 500W+ Products contain Product body, omnidirectional antenna, remote control
handle Size 510X 460X230mm
WS12
Fixed jamming box, built-in 8 -12 sets of RH drone jamming modules.It will
intefere the drone’s navigation signal, which forced drone to land or return
to its starting point.The jamming angle is 360 degrees. Jamming
range(1000 – 3000m), and can continuously counter the drone. Features:
1. Interference frequency band can be customized. 2. Built-in high-gain antenna jamming range, jamming range 1000 to 3000 meters. 3. The chassis is equipped with 4 waterproof cooling fans to ensure continuous operation. 4. The antenna and the main body can be easily assembled/disassembled.
WS16
Car Jamming Box, easy to install drone on the roof of a car or building
Jamming equipment, built-in 4-10 sets of RH drone jamming modules, equipped with high-gain directional antennas. It will intefere the drone’s
navigation signal, which forced drone to land or return to its starting
point. Angle is 360 degrees. Jamming range (1000 – 2000m), and can
continuously counter the drone. Features:
1. Interference frequency band can be customized. 2. Built-in high-gain antenna jamming range, jamming range 1000 to 3000m. 3. Can be mounted on the roof, powered by the vehicle or a mobile power supply. 4. The antenna and the main body can be easily assembled/disassembled, which is convenient for
customs clearance. 5. Equipped with connecting wire, the jamming switch can be controlled in the car. Name Chassis type
countermeasure
equipment Function Forced landing, removal
Interference
frequency
420-450MHZ
825-960MHz 1100-1300MHZ
1360-1450MHZ
1560-1620MHz 2400-2500MHz 5150-5300MHz 5725-5875MHz more Machine weight 28kg Omni-directional countermeasures
1000-2000m Protection class IP65 Direction of defence Omnidirectional 360° Whole machine power 400W+ Products contain Product body, omnidirectional antenna, remote control handle Size 300X 260X160mm
Name Chassis type countermeasure equipme
nt Function Forced landing, removal
Interference
frequency
220MHz～350MHz 350MHz～470MHz 470MHz～600MHz 600MHz～730MHz 730MHz～910MHz 910MHz～1100MHz 2400MHz～2560MHz 5600MHz～5860MHz
External Control Air switchOmni-directional countermeasures 1000-3000m Supply voltage DC: 24VStructural
dimensions 565*565*300mm
Packing size 600*6000*400mmPacking weight
≤18KG
Machine weight ≤16KGPower consumption
≤1100W
Output Power 47dBm（50W)
Power interface Aviation socket WS20-2
RF Interface NF impedance50ohmsAntenna type Omnidirectional dipole antenna Antenna Gain 5～8dBi
Antenna Standing
Wave
≤2.0 Antenna Power capacity
100W01 WS26
WS26
The fixed anti-drone cover is equipped with 8 sets of anti-drone modules and high-gain directional
antennas. It can interfere with the navigation signals of drones, forcing them to land or make an
emergency landing. Interfering with the remote control and video transmission signals of drones will
cause them to return to the take-off location. The interference angle is 360 degrees. The
interference range is 1000 – 3000 meters. It can continuously emit anti-drone interference signals to
force drones to land or return. Features:
1. Frequency bands and power can be customized as per requirements. 2. Built-in high-gain antenna, simple installation, plug and play. 3. The machine has good waterproof performance. 4. The device is equipped with a quick switch, allowing you to freely choose to activate the
interference frequency band or link with detection devices for intelligent countermeasures
Ø Fixed drone positioning equipment
Ø Vehicle-mounted drone detection jamming
equipment
Ø Suitcase drone positioning equipment
Ø Handheld drone positioning equipment
Ø •Handheld drone detection equipment
Drone detection series
TQ01 fixed
It is a drone positioning equipment integrating drone detection, early warning, identification, direction finding, positioning and other
functions. A single station can achieve multi-target simultaneous direction finding, and achieve accurate positioning and trajectory trackingof target drones. The equipment adopts passive spectrum detection technology, has no environmental interference and high concealment.
It can work offline on a single machine, has an integrated industrial design, high integration, and strong anti-interference ability, andissuitable for deployment in military and police scenarios. Features:
1.100MHz-6GHz spectrum scanning, support spectrum graph and waterfall graph display. 2. It can be linked with countermeasure or decoy equipment to deal with the target. 3. A single device can locate some types of drones and pilots, and multiple devices can be networked to achieve linkage networking, precise positioning, and trajectory tracking. 4. It can distinguish between cooperative and non-cooperative drones. When a cooperative drone is detected, the device will not issueanalarm, and cooperative drones can be marked as trusted.
02 TQ01 fixed
Interference frequency 100MHz～6GHz Detection radius 1～10km
Number of detected targets ≥30 Detection mode 360°Passive detection Direction finding frequency band 2GHz～6GHz Direction finding distance ≥3km
Number of direction finding targets ≥3 Direction finding accuracy 3°～10° Direction finding refresh rate 10～30s/m
Positioning error ≤10m
Number of positioning tracks ≥5 Scanning range 100MHz～6GHz Detection and identification of drones Common drone brands such as DJI, Doton, Feimi, Dahua, Haoxiang, andother self-made drones, WiFi drones, and most other models on themarket Models Single station can locate Drone models
(including pilots) DJI Mavic, Air, Mini, FPV, Avata and other series
02 TQ03 02 CH11
TQ03
The fixed unmanned aerial vehicle (UAV) detection and positioning equipment is a type of UAV detection and positioning device
that is permanently installed and equipped with an integrated control system for UAVs. This device can monitor multiple
dimensions of information about UAVs within the monitored area, such as the serial number, model, position (latitude, longitude, azimuth), speed, altitude, elevation, take-off point, return point, flight path, and remote control unit position (latitude, longitude, azimuth), through in-depth analysis of the UAV signals and data mining. Features: 1. It can identify and detect various common brand drones such as DJI, Autel, Dahua, Haixiang, as well as homemade
drones like cross-country aircraft and WiFi devices, covering the vast majority of models available on the market. 2. Passive detection, without causing electromagnetic pollution, is environmentally friendly. 3. The equipment supports continuous detection at all times. 4. It can be linked with jamming equipment and navigation deception equipment.
CH11
The portable drone detection and positioning device is a suitcase-shaped, soft and
hard all-in-one portable drone monitoring device.The device conducts in-depth
analysis and data mining of drone signals.It can detect the serial number, model,
location, speed, etc. of the drone within the detection range. Degree, height, altitude,Real-time detection of multi-dimensional information such as take-off point, return point, track and pilot position.Standalone or networked, deployable in seconds,
flexible, touch screen operation, simple to use. Features:
1. Can detect DJI, Autel, Dahua, as well as homemade machines and WiFi machines, Various models including flying drones. 2. Display the flight trajectories of multiple target drones in real time. 3. The single machine can locate and display the position of the drone and pilot in real time within1000-3000m. 4. Support black and white list settings. 5. The detection antenna and display screen can be folded and stored for easy carrying. Detect and identify drone
types Common drone brands such as DJI, Doton, Feimi, Dahua, Haoxiang, and other self-made drones, WiFi drones, and most other models on the market
Locable drone model
DJI Mavic, Air, Mini, FPV, Avata and other models Detection frequency band (Hz) 900M, 1.2G, 2.4G, 5.2G, 5.8G
Detection positioning distance 1~10km
Detection height 0m~1000m
Number of targets that can be
detected simultaneously
≥5 flights Can track and display the
trajectory of drones at the
same time
≥5 items Positioning accuracy ≤10m
weight ≤25kg
size (513mm*462mm*187mm)±2mm
Power consumption ≤100W
External power supply voltage 100~220V AC
Operating temperature -20~65℃
Protection level IP65
Working Mode Radio detection Working frequency band 900MHz , 1.2GHz, 2.4GHz, 5.2GHz, 5.8GHz Spectrum detection distance 1000-5000m
Locating drones and pilots 1000-3000m
Swarm Detection ≥5 flights (simultaneous)
Track display ≥5 items Device size L*W*H:520mm*415mm*224mm
Battery life About 4 hours (replaceable battery and external power supply)
Operating temperature -20℃~65℃
Protection level IP65 (box closed)
02
CH09
Handheld drone positioning device is a drone spectrum detection, It is a single-soldier portable product that
integrates regulatory functions such as protocol analysis and RID recognition. A single machine can realize
real-time detection and early warning of drones. It has precise positioning and trajectory tracking.The product
has a compact design, is easy to carry, and has a long battery life. It can be used in major event security, guard mission support, public security patrol, special counter-terrorism, political nuclear Low-altitude security
in key areas, border defense, airports, power and petrochemical parks, etc. Features: 1. Single machine can locate the position of drone. 2. Detect drones from 1000-4000m through spectrum analysis and identify them through spectrum
analysis. Locate the drone and pilot from 1000-2500m. 3. Can detect and identify homemade drones. 4. Can identify the unique serial number of the machine. Like DJI series drones, RID protocol drones, WIFI drones, etc.
02 CH09 CH03
CH03
The handheld drone detector adopts low power consumption design and highly integrated design. It hastheability to communicate with mainstream DJI, Autel, FPVS and other drones using OFDMhigh-definitionimage transmission. Features:
1. Can identify DJI, Autel, etc. using OFDM high-definition image transmissionrotor-wingdrone;
2. Can detect 300MHz-6200MHz using analog diagram Various types of flyingmachines;3. Sound and light alarm: headphone sound alarm, external sound and light alarm. Headphone function: Ability to receive alarm sound through headphones;
4. Support Chinese, English and Russian. Detection frequency band 100MHz～6GHz Detection Radius 1.5~2km (urban environment) 2~3km (open environment)
Response time 3~5s Targeting range 1~2km (urban environment) 2~3km (open environment)
Detection quantity ≥10 flights (simultaneously)
Battery life 3~4h
Host size L*W*H: (185mm*80mm*33mm)±5mm
weight (650±10)g
Battery capacity 8000mAh
Battery life 3 ~4 hours Charging time ~3 hours Screen size 6 Inch
Screen resolution 1080*2160 pixels Operating temperature -25~40℃
Storage temperature -35~40℃
Receiving frequency band 300MHz-6200MHz
Identify Type OFDM high-definition image transmission signal, Flying drone FManalogimagetransmission Detection distance ≥1km
Detection sensitivity Better than -96dBm
Detection alarm mode Headphones, sound, light, vibration
Logging Support no less than 500 alarm records Upgrade and data export interface mircoUSB
powered by Removable lithium battery (type-c charging)
Battery life ≥6 hours (single battery)
Structural dimensions ≤135mm×60mm×35mm (host excluding antenna)
Operating Weight ≤500g (including single battery)
Waterproof grade IP65
Ø Fixed detection and defense equipment
Ø Vehicle-mounted drone detection and defense
system
Ø Detection counter gun
Drone detection jamming system
TQ01-JM01
Fixed detection and defense equipment integrates drone detection, early warning, identification, and measurement . It integrates the functions of direction finding and positioning, and a single station
can realize the simultaneous direction finding of multiple targets. Realize accurate positioning and
trajectory tracking of target UAV. Jamming equipment, built-in 8 -12 sets of RH drone jamming modules, equipped with high-gain directional antennas. The jamming angle is 360 degrees. Jamming range (1000 – 3000meters), can continuously counter the jamming signal of the drone, making the drone be forced landing or return. Features: 1. Automatically initiate jamming after detecting a drone. 2. Locate drones within 2000-5000m through spectrum, and locate drones and position of the pilot within 2000-5000mthroughprotocol analysis. 3. The jamming box can be customized with jamming frequency bands as required. 4. It can detect and identify more than 800 types of drone models.
03 TQ01-JM01
Detection frequency band
100MHz～
6GHz Counterattack distance
≤1000-3000m
Detection radius 1～10000m Host size
Length 350mm*Width (thickness) 190mm*Height 490mm
Number of detected
targets ≥30 flights Countering the weight of the host 16kg Detection mode
360° passive
detection
power supply 220V / 2.36A Direction finding
frequency band
2GHz～6GHz Omnidirectional antenna Weight: 3kg; Length: <650mm Direction finding distance ≥3km Power supply Built-in battery power supply, or AC110V- 220V AC power supply Number of direction finding targets No less than 3 flights System protection Temperature protection, standing wave protection Direction finding accuracy 3°～10° Cooling System Built-in intelligent cooling system, continuous operation > 12 hours; Direction finding
refresh rate
10～30
times/minute
Internal battery Built-in 20A battery, continuous use > 1 hour Positioning error ≤10m Charging method External 4A charger Number of positioning tracks ≥5 flights Counterattack distance
at the same time Frequency scanning
range
100MHz～
6GHz Detection host weight ≤15kg
03 TQ02 03 LS03
TQ02
Vehicle-mounted drone detection jand jamming equipment for drones to be detected,
identified and countered. The system integrates collaborative spectrum sensing and
spectrum analysis technologies by using the received drone features. By using radio
jamming and blocking technology, illegal drone detection is more easily to achieve. Features: 1. Integrated detection and countermeasure design. 2. The detection range is 100MHz~6GHz. 3. Support spectrum detection to detect drones and analyze the locations of
drones and pilots. 4. The equipment is equipped with shock-absorbing springs so that it can be used
in various complex environments.
LS03
The detection countermeasure gun can locate the position of the drone through protocol analysis. Andprovide accurate latitude and longitude. The signal can make the drone land. The remote control andimage transmission signals of the drone will make the drone return to the take-off point. The jammingangle is 45 degrees. The jamming range
is (1000 – 2000meters), which can continuously counter
the jamming signal of the drone. Features:
1. Integrated detection and countermeasure design. 2. Single soldier deploys drone countermeasure gun. 3. Jamming: Set 5 frequency bands for interference. Working Mode Passive Detection Target Drone image transmission Working frequency band 100MHz~6GHz Detection Angle Horizontal: 0° ~360°; Vertical: 0° ~90° Detection distance
2-7 km (depending on the working conditions and target aircraft model)There are some differences)
Simultaneous detection and
identification quantity
≥10 (5 different manufacturers)
Discovery time ≤4s Detection of power consumption ≤50W
(880~950)±10MHz (43±2)dBm
(1550~1640)±10MHz (43±2)dBm
(2400~2510)±10MHz (43±2)dBm
(5700~5900)±10MHz (43±2)dBm
size φ*H:600mm*425mm
weight ≤25kg
Operating temperature -20℃~60℃
Storage temperature -60℃~85℃
System power supply AC 220V power supply or mobile power supply
Interference
frequency band
900MHz, 1.5GHz, 2.4GHz, 5.2GHz, 5.8GHz Power consumption
≤320w Working distance 1000-2000m
Protection
level IP 65
Radiation beam
angle
≥30° Operating
temperature
-20℃ ~ 60℃OLED LCD display
Display device status, battery
status, working mode Storage
temperature
-40°C ~ +65°C (optimal battery storagetemperature recommended: -20°C~+25°C)OLED screen size 3.5 in Product
Weight ≤ 7 kg (including battery)
Battery life
≥ 30 minutes (continuous operation) Product size
880 mm × 100 mm× 330 mm(length, width,height)
Power supply Lithium battery (replaceable) Detection
distance
≥ 1000 m (depending on the environment andmodel)
Charging method DC29.4V/6A
Detection
frequency
band
2.4GHz, 5.8GHz Charging time 2h Battery life ≥ 20 h (detection standby state)
Ø Drone detection PCBA board
Ø RH jamming modules
A350
Drone detection PCBA board It adopts low power consumption design and highly
integrated design, and has DJI, Docom and other rotary-wing drones using OFDM
high-definition image transmission. Features: 1. Simple machines can realize drone detection. 2.Support detection and direction finding. 3. Can be easily applied to handheld detection and jamming guns
04 A350
Drone Defense Module
Receiving frequency band 300MHz～6200MHz Key frequency band 1 1.2G FPV frequency band (1000～1500)
Key frequency band 2 5.8G FPV frequency band (4900～6200)
Key frequency band 3 2.4/5.1～5.9 UAV frequency band
Other frequency bands FPV frequency band (300-1000, 2300-2500, 3100-3500)
Receiving Type OFDM high-definition image transmission signal, Flying drone FManalogimagetransmission signal
Receiving distance ≥1000m
Antenna interface type IPEX-1 mother seat
Interface 1 300MHz～4.9GHz omnidirectional antenna
Interface 2 2.4G, 4.9GHz~6.2GHz omnidirectional antenna
Interface 3 2.4/5.1～5.9 UAV directional antenna Supply voltage DC 5V～36V
Working power consumption ≤5W
Work Environment -40℃ ～+65℃
Structural dimensions 100mm×50mm×8mm
04
RH jamming modules RH jamming modules are used for UAV jammers. They are the core components for making various signal jammers.Signal suppression
equipment used in electronic warfare, mainly used
forcommunications,Countermeasures, satellite, navigation, suppression and
countermeasures Features: 1. Using the third-generation semiconductor material gallium nitride power tube, it has good heat dissipation, high
efficiency and long service life. 2. The frequency band and power can be customized as needed. 3. The voltage stabilization circuit is designed inside the module to ensure the stability of the module’s input voltage
and provide a guarantee for the module’s stable output power.
04 RH jamming modules RH jamming module is usedfor UAVjammersRH jamming module is used for UAV jammers
It is the core component for manufacturing various signal jammers. It is often used in electronic warfare. Signal suppression equipment, mainly linked to detection equipment to achieve accurate detectionof dronesFrequency band attack. Jamming bands and power support:
20W 400-2700MHZ 20w, 50W 1000-6000MHZ,100W300-1500MHZ, 100W 1500-2500MHZ
100W 2500-4000MHZ, 100W 4000-6000MHZ,300-6000MHZ15w, 400-6500MHZ 20w
300-1600 50W , 1500-2500 50W,2400-4000 50W, 4000-600050WPower FREQ(MHZ) Power(dBm) Current(A) Voltage(V)
100W 420-450 50+1 ≤7 28-32
100W 840-860 50±1 ≤7 28-32
100W 900-930 50±1 ≤7 28-32
100W 1180-1280 50±1 ≤7 28-32
100W 1440-1445 50±1 ≤7 28-32
100W 1550-1620 50±1 ≤7 28-32
100W 2400-2500 50±1 ≤7 28-32
100W 5150-5350 50±1 ≤7 32-36
100W 5725-5850 50±1 ≤7 32-36
Test items index unit Remark
Frequency range 4000-6000 MHz Operating voltage 32 V 28-32
Maximum output power 100 W 100W@10.2A typical
Amplifier efficiency 27 % @100WMaximum Gain 45 db MaximumPower GainGain Flatness ≤5 db
Standard input power 6 dbm
Maximum non-damaging power ≤10 dbm
Input port VSWR ≤2 No power, network test
Working environment temperature (℃) -10～+55℃ ℃
Power stability ±1.0@-40℃～+55℃ dB
Power supply requirements ≥13A@+32Vdc; Continuous wave output 100WPower supply interface Feedthrough Capacitor
Ø Antennas
05 Antenna
Drone DefenseAccessories
Antenna
frquency
433MHz、900MHz、1.1G、1.2G、
1.5 G、2.4G、5.2G、5.8G
Antenna gain 5-16±1dBi
Antenna
standing wave
≤2.0/≤1.5
Maximum power 50W
Horizontal lobe 65°+5° Vertical lobe 32°±5° Antenna
connector N male inner Antenna size 1200X280X80MM 600X280X80MM
Antenna frquency 433MHz、700MHz、900MHz、1.1G、1.2G、1.5 G、2.4G、5.8GAntenna gain 3-10±1dBi
Antenna standing wave
≤1.5
Maximum power 100W
Horizontal lobe 360° Vertical lobe 55±10° Antenna connector connector embedded
Antenna size 20*25*32MM600*32*800MMAntenna
frquency
433MHz、900MHz、1.1G、1.2G、
1.5G、2.4G、5.2G、5.8G
Antenna gain 5-16±1dBi
Antenna
standing wave
≤1.8
Maximum power 50W
Horizontal lobe 60° Vertical lobe 1°±10° Antenna
connector N male inner Antenna size 390x390x50MM
Antenna frquency 433MHz、900MHz、1.1G、1.2G、1.5G、2.4G、5.8GAntenna gain 3-18±1dBi
Antenna standing wave
≤1.5
Maximum power 50W
Horizontal lobe 53° Vertical lobe 60°±10° Antenna connector SMA male inner

___________________________________________________________________________________________________________________________________________________
Official Announcement: Anti-Drone System Insurance Coverage
We are pleased to formally announce that our vessel’s Anti-Drone Defense System is now officially integrated into our comprehensive marine insurance policy.

This coverage marks a significant step in our risk management strategy, providing full protection for the system’s hardware and associated operational liabilities. By securing this endorsement, we ensure both the longevity of our security infrastructure and the continued safety of our maritime operations against emerging aerial threats.

The inclusion of this technology under our primary policy underscores our commitment to maintaining the highest standards of vessel security and operational resilience.

Delivery Time 3-5 days
