Based metal indirect 3D printing solution（F-MIM）3D printer Debending equipment Sintering equipment Different from the direct additive manufacturing process of materials such as resin plastics or metals, F-MIM technology is an innovative solution for indirect 3D printing technology combining 3D printing and powder metallurgy. 3D printing only completes the production of high-precision green body, and also requires powder metallurgy related processes such as debinding +sintering to obtain consistent and excellent products. MIM technology has the advantages of fast printing speed, lowcost, high
MIM-based metal indirect 3D printingsolutionmolding precision, good product performance consistency andwideprintablematerials.The printable material system is rich and comprehensive, includingstainless steel, die steel, high temperature alloy, titaniumalloy, refractorymetaland other metal materials, as well as ceramic materials such as zirconia, alumina,silicon carbide. The almost endless list of potential materials creates favorable objectiveconditions for 3D printing large-scale entry into the applicationmarket, andcanbe widely used in research and education, industrial manufacturing, aerospace,military defense, biomedical, automotive, mold manufacturing, newenergy,etc. .
filament 3D printing Green part Debinding Sintering Metal part
MIM-based metal indirect 3D printingsolution 1
● Overall quotation
Policy and service content
Item content
Installation training On-site service time: 5-8 days. The customer only has to pay for transportationandaccommodation expenses for the service engineer. Supporting consumable Free fitting: 1KG PEEK, 3KG stainless steel 316XL, 3KGPLA.software Free metal indirect 3D printing companion slicingsoftwareTool kit Free special tool kit
Price : (including printer + debinding furnace + sintering furnace). Quote valid for 30 days. Payment method: 50% prepayment in advance, Balance should be paid beforedelivery.Delivery period: 25-45 days. 1. Service:
a. The customers need to use the original consumables. If other consumables areneeded,they must be tested by our company before they can be used. Otherwise, theyarenotcovered by the free warranty;
b. It is forbidden to disassemble or repair the equipment without consent. If thereisanyproblem with the use of the equipment, please contact our technical staff for assistance;c. During the warranty period, our company will work with customers to carryout
MIM-based metal indirect 3D printingsolution 2
equipment technical support and warranty work remotely. If on-site support is required,both parties will negotiate in advance. 2. After-sales policy
1. The whole machine is guaranteed for 12 months. During the warranty period, ourcompany provides remote technical support free of charge to assist customers insolvingmachine problems during use;
2. If a technician is required to provide on-site service, the customer shall paythetransportation and accommodation expenses for the service engineer. 3. During the warranty period, if there are parts with natural damage, we needtosenditback to our company for repair. Our company does not charge for maintenance, andthelogistics cost is borne by the customer;
4. Equipment problems caused by human causes and force majeure factors arenot includedin the free after-sales range. ● 3D printer description
high performance material 3D printer MAGIC-HT-PRO is a 3D printing device based on the principle of fuse deposition (FFF) technology, with printing temperatureupto450°C,hot bed temperature of 170 ° C, and 120 ° C cavity ,supports most of the 3Dfilamentonthemarket, including metal filament stainless steel 316XL, special engineering plasticsPEEK,PEKK, PPSU, ULTEM, general materials PA, PC, ABS, PLA, etc.
MIM-based metal indirect 3D printingsolution 3
3D printed green parts
MIM-based metal indirect 3D printingsolution 4
MAGIC-HT-PRO 3D Printer parametersPrinting Technology：Fused Filament Fabrication (FFF) Build Volume：310*310*480 mmProduct Dimensions：702*624*790mm *2 Packing Dimensions ：780*690*980mm*2Printing Temperature：Up to 450℃ Chamber Temperature：Up to 120℃Net Weight：205 kg. Packing Weight：235 kg Camera: optional
Build Platform：CARBON FIBER plate Layer Thickness：0.05-0.3 mmNozzles：double
Nozzle Diameter：o.4 mmfor Standard, availableforCustomizing. Print Speed：30-300 mm/s Supported File Types：STL、OBJ、3MFSupported Filaments：Metal filament,PEEK, ULTEM, PPSU, PA, PC, ABS, ASA,PETG,HIPS,TPU, PVA,CARBON,etc. Filament Diameter：1.75mmBuild Plate Temperature：up to 170℃ Position Accuracy：X/Y12.5 μmZ:1.25μmInput：100~240V, 50~60 Hz 2500W Output：DC 12V
File Transfer：SD card, USB, Wi-Fi Warranty：12 Month
Screen : 5’ Touchscreen
Software:Iemai,Cura,Simplify 3D,Compatiblewith other.
MIM-based metal indirect 3D printingsolution 5
The Advantage of MAGIC-HT-PRO
Advantage picture DescriptionDetachable extruder Easy replacement andmaintenance;High temperature
double extruder
450℃ Print temperature Expansibility;
Support printing (HT support printing);Two material or two colors printingLiquid cooling system
Liquid cooling print headBetter heat dissipationIncreased service life of accessoriesZ axis
Ball screw+
linear guide
High precision transmission;
(With High temperature resistant belt);XY axis drive
(cross shaft linear
guide)
Keep components in isolation fromtheconstanttemperature chamber
Improve the life of moving parts andreducemaintenance frequencyImprove equipment XY axis motionstabilityPrint temperature
450℃
Hot bed temperature
170℃
Provide high temperature printingconditionsSupports printing of high performancematerials
MIM-based metal indirect 3D printingsolution 6
Constant chamber
temperature 120℃
Maintain temperature gradient
Achieve better material crystallizationQuick release printing
platform
Easy model removal and platformreplacementDouble hot air
temperature system
More uniformtemperature;
The temperature is more effective ,andlessaffecttothe service life of the circuit and thetransmissionpart;
Material moisture proof
cabinet
Supporting moisture-proof cabinetProvide suitable lowhumiditystorageconditions for materials
With multi-functional toolboxPower Failure Recovery / Recovery of power off accident printing;Filament Absent
Warning
/ Reminding the material tobreak;
AUTO-leveling / AUTO-leveling hotbed
MIM-based metal indirect 3D printing solution 7
● Debending equipment description
introduces the special desktop debending furnace YM-D200, which is easy too perate and uses the principle of catalytic degreasing. It is suitable for the binder removal stage in metal indirect 3D printing.
Specification（YM-D200）Equipment name: debinding furnace Technical principle: catalytic degreasing Machine size：818*567*867mm Effective working size：235X235X285mmNet weight：80kg Feeding method: plug-in type
Tray size：230X260X10mm Placement height：140mmFurnace gas: nitrogen Gas Control: Glass Float Flowmeter
Acid feeding mode: suction cup metering pump Combustion method: electric heatingAcid consumption：20-100g/h Nitrogen consumption：500L/h
MIM-based metal indirect 3D printingsolution 8
● Debinding furnace
Composition name
Included components
/functions
Description
Main structure Stove, furnace, furnace door
The main part is composed of thehob, thefurnace, and the furnace door. Both the furnace and the furnacedoor arewelded airtight structures, whicharemadeofcorrosion-resistant stainless steel. Thefurnaceframe is not in direct contact withnitricacidand is made of carbon steel. The outer layer of the furnace has alayerofceramic fiber refractory material tohelpininsulation and insulatio
Nitric acid supply
system
Suction cup metering pump
The liquid concentrated nitric acidis directlydelivered to the furnace throughahigh-precision suction cup meteringpump.
Control mode: PLC automatic control
Exhaust gas treatment method: hightemperatureheating decomposition, combustionexhaust. Maximum working temperature: 200 ° C (usually
110 ° C)
Temperature control accuracy: 1‰(usingK-typethermocouple)
Furnace chamber temperature uniformity：±2℃ Surface temperature rise：≤50℃Furnace chamber warming time：20~30min （25~
110℃）
Total equipment power: single phase4KWNitric acid metering accuracy：±3% Gas control accuracy：±3%
MIM-based metal indirect 3D printingsolution 9
Heating and
temperature control
system
Heating jacket, temperature
controller, type K
thermocouple
The furnace cavity is heated by external
heating, with high-precision temperaturecontrol module and thermocoupletoachieveuniform and stable heating. Gas and piping systems
Stainless steel pipe, precision
regulating valve
Glass float flowmeter
The flow of nitrogen is controlledbyanadjustable glass float flowmeter, all of whicharemade of corrosion-resistant stainless steel
tubing. Connected with precision control valveandsolenoid valve. Electronic control
system
PLC、touch screen
All electrical parts are made of well-knownbrand products at home and abroad, andtheirperformance is superior and stable. HMI
Fully automatic operation
mode, process segmentation
parameter setting, real-time
State monitoring and alarm
The human-machine interface is a4.3-inchtouch screen
Real-time monitoring and alarmof equipmentoperating state temperature
Automatic operation mode andprocesssegmentation parameter setting
Temperature table graph display, manual
operation mode and parameter setting● Vacuum sintering furnace
introduces the special desktop vacuum sintering furnaceYM-S200, whichis easy to operate and uses the principle of high temperature vacuumsintering.It is suitable for the sintering stage of metal indirect 3D printing.
MIM-based metal indirect 3D printingsolution 10
Specification（YM-S200）equipment：Vacuum sintering furnace
Technical principle: catalytic degreasing(vacuumsintering)
Machine size：1450*2090*2700mm Effective working size：200X200X200mmEquipment weight: 1.25T Feeding method: manual feedingGas in the furnace: vacuum, argon Gas Control: Glass Float Flowmeter
Vacuum pump set: slide valve pump + Roots pu
mp
Heating method: low pressure graphiterodheating
Control mode: PLC automatic control
Insulation and insulation: graphite carbonfelt+furnace wall water cooling
Maximum working temperature: 1600 ° C (usually
1500 ° C)
Temperature control accuracy: 1‰(withtungsten-rhodium thermocouple)
Furnace chamber temperature uniformity: ±3 °C Vacuum and pressure control: Pirani vacuumgau
MIM-based metal indirect 3D printingsolution 11
● Vacuum sintering furnace
Composition name
Included components
/functions
Description
Main structure Stove, furnace, furnace door
Composed of a hob, a furnace body andafurnacedoor
The furnace and the furnace door are weldedairtightstructures
All have a water-cooled interlayer andtheinner layerismade of corrosion-resistant stainless steel. The outer layer is made of Q235 steel andthehobismade of carbon steel. Vacuum system
Spool valve pump + Roots pump, Pirani vacuum gauge
Pressure Transmitters
When the furnace air reaches about 250Pa, thepumpset automatically starts the Roots pump. Pirani vacuum gauges and pressure transmittersmonitor vacuum and pressure in the furnaceinrealtime
Cooling water
circulation system
Water-cooled pipe, water flow
control valve
Water temperature monitoring
system
The cooling water circulation systemis mainlyusedforwater cooling of structures such as furnacebodiesandfurnace doors.
ge + pressure transmitter
Furnace chamber heating time: 90~120 min (25~
1500°C)
Maximum heating power：25KWArgon consumption: 50~150 L/min adjustable Total equipment power:：32KW
MIM-based metal indirect 3D printingsolution 12
Heating and
temperature control
system
Built-in heating, high precision
temperature controller
Imported thermocouple
The graphite heating body is locatedoutsidethegraphite box and inside the graphite carbonfeltAchieve a more uniform thermal fieldandreduceheatloss, improve electrothermal conversionrateDue to the low voltage, the equipment issaferTemperature control using tungsten-rhodiumthermocouple and high-precision temperaturecontrolcomponents in the furnaceGas and piping
systems
Stainless steel pipe, precision
regulating valve
Glass float flowmeter
Control gas flow with high precisionflowmeterAll pipes are connected by corrosion-resistant stainlesssteel pipes
With precision regulating valve andsolenoidvalveElectronic control
system
PLC, touch screen
All electrical parts are made of well-knownbrandproducts at home and abroad, and their performanceis superior and stable. HMI
Fully automatic operation mode, process segmentation parameter
setting,Real-time status
monitoring and alarm
Human-machine interface is a 10-inchtouchscreenReal-time monitoring and alarmof equipment runningstatus
Temperature and gas flow graph display andstorageAutomatic operation mode and process segmentationparameter setting
MIM-based metal indirect 3D printing solution 13
● Company Profile
specializes in the development, production and sales of 3D printing equipment, providing3Dprinting solutions for high performance materials industrial applications;
MAGIC-HT-PRO/L/M were high temperature 3D printer designed for high performance materials;
YM-NT-750/1000 were industrial grade 3D printer designed for printing large size models;
As a result of high quality standards for product development and production, all 3Dprintersarecurrently CE and ROHS certified;
Imai attaches great importance to brand building and has obtained trademark certificates from China,the United States and the European Union;
is committed to the pursuit of core technology research and development, andhasobtainedsoftware copyright, invention patent, utility model patent, design patent, high-techenterprisetitle(Please visit our website for high-definition image.
The 3D printing solutions have been applied to: aerospace, automotive, petrochemical, medical,dental and electronics manufacturing. ● Our Certifications
CE ROHS software copyright patent 01 patent 02 patent03US trademark EU trademark China trademark high-tech enterprisetitle
MIM-based metal indirect 3D printingsolution 14
● Metal indirect 3D printing results showBefore —– 3D printed green parts
After—— after debinding and sintering
MIM-based metal indirect 3D printingsolution 15 .
